Spacing:3.5/3.81mm
Material and Plating
Plastic parts;PA66,UL94V-0
Cage:Brass,Tin plating
Screw:M2.0,Steel,Zn Plating
Terminal：Phosphor bronze，Nickel plating
Electrical performance
Rated voltage：300V
Rated current：8A
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000V
Withstanding Voltage:AC1500V/1Min
Mechanical properties
Ambient temperature:-40℃_~+105℃
MAX Soldering:+250℃,5s
Wire diameter:28-16AWG 1.5mm2
Torque:0.5Nm
Strip length:7-8mm
