Material and Plating
Plastic parts;PA66,UL94V-0
Welding needle:Brass,Tin plating
Screw:M5,Steel,zinc Plating
Square box:Brass,Nickel plating
Electrical performance
Rated voltage：1000V
Rated current：90A
Contact resistance:20mΩ
Insulation resistance:5000MΩ/1000v
Wire diameter:20-2AWG
Withstanding Voltage:AC3500V/1Min
Mechanical properties
Ambient temperature:-40℃_~+105℃
MAX Soldering:+250℃,5s
Torque:2.0Nm
Strip length:18mm
